Genuine OEM·Whirlpool

W11744514Replaces 2 older numbers

Whirlpool W11744514 Refrigerator Wire Harness - Genuine OEM

Whirlpool W11744514 Refrigerator Wire Harness - Genuine OEM

$34.47 USD
$58.25 USD $34.47 USD
Sale Sold out
Shipping calculated at checkout.
Available to order Ships on the next business day
  • Fit checked against the maker’s own model list
  • Genuine OEM part, one-year warranty
  • 365-day returns, unused and in the original box
  • Ships from a U.S. warehouse, tracked
Also known by these numbers

If your old part carries any of these, this is the one you want.

  • W11293520
  • W11526233

Whirlpool W11744514 is a wire harness for refrigerator appliances. New, genuine Whirlpool OEM — ordered from the brand's own distributor, not an aftermarket copy.

Read the number off your old part

Look for the number stamped or printed on the part itself. If it says W11744514, or any of the 2 older numbers listed under Compatible parts below, this is the replacement. Every one of them is discontinued and every one leads here.

Shipping box

Weight and size of the parcel as it ships: 0.48 lb · 8.3858, 6.1023, 2.3228 in. These are the carton, not the part — do not measure your old part against them.

Does it fit yours?

Enter your model number in the box above for a straight answer, or read the full list under Compatible models below. Send us the number and we will confirm it before you order.

Buying from us

  • One year warranty, backed by FIXIT PARTS — if it fails in the first year we replace it.
  • 30 day returns — unused and uninstalled, in the original box.
  • Ships the same business day on orders placed before 12:00 PM Pacific.

Part numbers on this page

Manufacturer numbers: W11293520, W11526233.

Models this part fits

16 models

Fits: AZF33X16DW10, AZF33X18DW08, AZF33X20DW08, GAFZ30FDGB06, GARF30FDGB01, GARF30FDGB04, MZF34X16DW10, MZF34X18FW08, MZF34X20DW08, WRR56X18FW03, WRR56X18FW06, WSR57R18DM03, WSR57R18DM06, WZF34X16DW10, WZF34X18DW08, WZF34X20DW06.

Also fits these brands

  • Whirlpool
  • Maytag
View full details

Model cross reference

This part W11744514 works with all 16 models listed, all of them refrigerators.

Need help finding your model number?
Model number ManufacturerAppliance type
AZF33X16DW10 WhirlpoolRefrigerator
AZF33X18DW08 WhirlpoolRefrigerator
AZF33X20DW08 WhirlpoolRefrigerator
GAFZ30FDGB06 WhirlpoolRefrigerator
GARF30FDGB01 WhirlpoolRefrigerator
GARF30FDGB04 WhirlpoolRefrigerator
MZF34X16DW10 WhirlpoolRefrigerator
MZF34X18FW08 MaytagRefrigerator
MZF34X20DW08 WhirlpoolRefrigerator
WRR56X18FW03 WhirlpoolRefrigerator
WRR56X18FW06 WhirlpoolRefrigerator
WSR57R18DM03 WhirlpoolRefrigerator
WSR57R18DM06 WhirlpoolRefrigerator
WZF34X16DW10 WhirlpoolRefrigerator
WZF34X18DW08 WhirlpoolRefrigerator
WZF34X20DW06 WhirlpoolRefrigerator
